Cone Crusher Spare Parts
Overview
Cone crushers play a vital role in mining and aggregate production, particularly in secondary and tertiary crushing stages. Their stable operation ensures consistent particle size control and steady plant output. Core components such as the mainshaft, bushings, and eccentric assembly are subject to high-impact forces and are key to overall system durability and efficiency.
As a professional aftermarket manufacturer, GUBT supplies high-quality, fully compatible replacement parts engineered to improve reliability, reduce maintenance costs, and maximize long-term returns.
Materials
The table below lists commonly used material grades for cone crusher parts, categorized by type and their key properties:
| Category | Material Grades | Key Properties |
|---|---|---|
| Carbon Steel | 20#, Q235, 25#, 35#, 45# | Balanced strength and ductility, suitable for structural components |
| Low Alloy Steel | Q345D, Q355ND, Q420, Q460, Q690, Q690D | Enhanced strength and toughness through heat treatment |
| Quenched Alloy Steel | 30CrNiMo, 30Cr2Ni2Mo, 34Cr2Ni2Mo, 40Cr, 42CrMo, 40CrNiMoA, 17Cr2Ni2Mo | Excellent fatigue resistance and high load capacity |
| Wear-Resistant Steel | NM400, NM450, NM500, NM600, HARDOX400 | Exceptional abrasion resistance, ideal for high-friction applications |
| Cast Iron | HT250, HT350, QT400-15, QT500-7, QT600-3, QT700-2 | Suitable for housings and base structures, excellent casting performance |
| Ductile Iron | G28Mn6, 20Mn, 16MN | Superior toughness and impact resistance |
| Bronze | ZCuSn10Zn2, ZCuPb15Sn8, ZCuPb10Sn10 | Low-friction, self-lubricating, ideal for bushings and sliding parts |
| Stainless Steel | SUS304 | Corrosion-resistant, used in seals, washers, and fasteners |
| Aluminum Alloy | AL | Lightweight and corrosion-resistant, used for non-load-bearing parts |
| Elastomers & Plastics | RUBBER, NBR, FKM, NYLON, PU | Shock-absorbing, chemical-resistant, flexible sealing |
| Composite Materials | IRON FELT, PF, TC, PE1000 | Damping, wear-resistant, protective lining material |
Item Categories
| Category | Products |
|---|---|
| Structural Components | Frame, Main shaft, Eccentric Assembly |
| Transmission Components | Bushings, Pinions & Gears, Pinion shafts & Countershafts |
| Adjustment & Fasteners | Adjustment Rings & Bowls, Thru Bolts, U-Bolts, Adapter Rings, Wedges |
| Protection & Sealing | Epoxy Backing, Support Rings, Torch Rings, Filler Rings, Spider Rim Liners |
| Common Parts | Feed Plates, Mounting Bolts, Head Assemblies |
Supported Crusher Models
We support but are not limited to the following brands and series, offering replacement parts for components such as the frame, eccentric assembly, bushings, adjustment mechanisms, and fastening systems:
| Brand | Representative Models |
|---|---|
| Allis‑Chalmers | 600 Hydrocone, 4‑60 HYD, AC36, AC42, AC55, AC4248, AC500, AC1366, AC3655 |
| Chyi Meang (CMC) | 2S, 3S, 4S, GP5 |
| Dragon / Cedarapids RC | RC36, RC45, RC54, RC54‑FH, RC54‑FH‑CLASSIC, RC66 |
| Euro Cone (CFBK) | CFBK36, 940, 1100, 1150, 1360, 2120 |
| Faco | TS90, TS120 |
| FLSmidth | RXL‑200, RXL‑300, RXL‑300+, RXL‑400 |
| Jaques | 35, G50 |
| Kleemann | MCO9 EVO / S EVO, MCO11 EVO / PRO, MCO13 |
| KPI‑JCI Kodiak | K200, K300, K350, K400, K500 |
| Kue‑Ken | 18, 28 |
| Liming | CSB160, HPC220, HPT300, HPT500 |
| Lokomo | G258 |
| Metso GP / MP / MX / WF | GP100 – GP550 series, GP7, MP800 – MP1250, MX3, MX4, WF100 – WF800, G1815 – G610, LT300 |
| Minyu MCC / MSP | MCC/MCS/MCF/MCSS 600 – 1680HN, MSP100 – MSP400 (F / M / C) |
| NMS | CC400 |
| Nordberg G‑Series | G1810, 2610, 3210, 3812, 3815, 5015, 610 |
| Omnicone | 937, 1144, 1352, 1560 |
| Rexnord | GYR22, 36, 42, 42‑70, 48, 54, 66, 84 |
| Kharkov | KKD900 – KKD1500, KSD/KMD 1200 – 2200 |
| Sandvik CS / CJ / H‑Series | CS420 –CS660; CH420 – CH895; H60, H7800 |
| Shanghai PYB / PYFB / PYGD etc. | PYB900 – PYB2200, PYFB900 – PYFB1600, PYGB/PYGD/PYDF/PYGF series |
| Shanmei SMH | SMH120C, SMH250C |
| Shaorui / NHI | 185, SC185Z, SC220, SRC220, SG160 |
| Shibang | CS75B |
| Svedala Hydrocone / Superior | 36M84, H36 – H8800, S2000 – S6800 |
| Symons (Standard & Short Head) | 2 ft – 7 ft, 4800 SH HD, 5100 |
| Telsmith | 24VFC, 36 – 68 series, 44/48/52/57/66 S/FC/H/SBS, 6614, T300, T400, 1100, 1110 |
| Terex Cedarapids / Maxtrak / MVP | MVP280 – MVP550, Maxtrak1000 – 1500, C1540 – C1554 |
| ThyssenKrupp Kubria | FM 90, 1140G, G110, G150 |
| Trio | TC36 – TC84X, TP350 – TP600 |
| Metso HP | HP100, HP200, HP300, HP400, HP500, HP700, HP800 |
| Metso GP Fine | GP100, GP200, GP300, GP330, GP550, GP11F, GP220 |
| GP Secondary | GP100S, GP200S, GP300S, GP500S |
| Sandvik CH | CH420, CH430, CH440, CH540, CH550, CH660, CH860i, CH865i, CH870i, CH890i, CH895i |
| Sandvik CS | CS420, CS430, CS440, CS550, CS660 |
| Terex / Finlay | 1000, 1150, 1300, 1400, 1500 Maxtrak, C-1540, C-1545, C-1550, C-1554 |
Technical Glossary Of Cone Crusher Liners
- Eccentric Assembly: A key mechanism that drives the mainshaft in an eccentric path, influencing crushing stroke and output efficiency.
- Mainshaft: The central rotating shaft that transmits torque and bears vertical loads, critical to the crusher’s drive system.
- Bushing: A wear-resistant sleeve, usually made of bronze, used between moving and fixed parts to reduce friction and ensure alignment.
- Hydraulic Cylinder: A hydraulic actuator used for CSS adjustment, overload protection, or lifting assemblies during maintenance.
- Adjustment Ring: A structural ring for controlling the Closed Side Setting (CSS); many models use hydraulic mechanisms for precise, on-the-fly adjustment.
- Torque Arm: A structural support that stabilizes and aligns torque transmission, especially in eccentric drive configurations.
- Locking Nut: A securing component that holds the crushing head assembly in position, preventing loosening due to vibration or cyclic loads.
- Backstop Device: A safety mechanism designed to prevent reverse rotation of the mainshaft during shutdown or abnormal operation.
- Flow Divider: A hydraulic control element that evenly splits fluid flow between multiple cylinders or actuators.
- Hydraulic Filter: Maintains fluid cleanliness within the hydraulic system, protecting components and ensuring stable system pressure.
Frequently Asked Questions
- When should the mainshaft be replaced?
If you notice overheating, unusual vibration, or visible cracks, the mainshaft should be replaced immediately to prevent further damage.
- What causes the adjustment ring to bounce?
This may result from uneven feed, overloading, or loose contact between components. Check the weight balance and ensure all fasteners are properly tightened.
- Is GUBT an OEM?
No. GUBT is a professional aftermarket manufacturer offering high-quality, OEM-compatible parts at competitive prices.
- Does GUBT maintain stock for fast-moving parts?
Yes. GUBT holds large inventories of critical wear and structural components like bushings, wedges, and assemblies to ensure fast delivery worldwide.
- How should the hydraulic system be maintained?
Regularly check hydraulic oil levels, clean filters, and inspect system pressure and responsiveness to avoid failures or delays.
